How to build Your Underwater Connector

Step 1

Order Connectors and Backshells

Female Bulkhead Example:

+

Female Connector

Bulkhead Backshell

=

Female Bulkhead Assembly

Male Inline Example

+

Male Connector

Inline Backshell

+

=

Female Locking Ring

Male Inline Assembly

Step 2

Order Supplies

Epoxy

Potting your underwater connector

Mixing Nozzles

Fully mixing the epoxy for potting

Dispensing Needle

Backfill the inside of your connector with epoxy

Assembly Jig

Keep everything in place while the epoxy cures

Step 3

Put it all together in 3 easy steps

Solder wires to connector

Up to 18AWG will fit

Prep for Bonding

Clean and degrease all surfaces to be bonded

Glue it together

Pot the connector and let it cure.
